VIEWSONIC LS711HD PROJECTOR

Short-Throw Laser. Bright 1080p for Sim Bays.

4200-lumen Full HD laser projector with a 0.49 throw — 100″ from ~1.1 m.

The ViewSonic LS711HD is a compact, lamp-free short-throw projector ideal for golf simulators. It delivers crisp 1080p detail, up to 4200 ANSI lumens of brightness, and a flexible 0.49 throw ratio that fills big screens from close range — keeping you out of the beam in tight bays. The laser light source is rated for up to 30,000 hours for low-maintenance installs.

Key Benefits

• ⛳ True Short-Throw – 0.49 throw shows a 100″ image from ~3.6 ft / 1.1 m, great for single-garage setups.
• ⛳ Bright, Clear Picture – Up to 4200 lm for punchy visuals even with some ambient light.
• ⛳ Laser Convenience – Instant on/off and up to 30,000-hour light-source life reduce upkeep.
• ⛳ Sim-Friendly Modes – Horizontal/vertical keystone and 4-corner adjustment simplify alignment; 360°/portrait capable for flexible installs.
• ⛳ Golf-Ready – Designed with a dedicated Golf Mode and wide software compatibility for lifelike colours on virtual courses.

Features & Technical Specs

• ⚪ Resolution: Full HD 1080p (1920 × 1080), 16:9 aspect
• ⚪ Brightness: up to 4200 ANSI lumens
• ⚪ Contrast: up to 3,000,000:1 (dynamic)
• ⚪ Throw Ratio: 0.49 (100″ @ ~1.1 m / 3.6 ft)
• ⚪ Image Size: ~80″–150″ (typical sim range), up to 300″ max
• ⚪ Alignment: H/V keystone ±15°, 4-corner; 360° projection & portrait mode
• ⚪ Light Source: Laser phosphor, up to 30,000 hours
• ⚪ Inputs: 2 × HDMI 2.0, USB-A power, audio out; RS-232 control
• ⚪ Size/Weight: compact chassis ~3 kg class (single-chip DLP)

Recommended Sim Use

• 🎯 Placement: Plan roughly ~1.1 m lens-to-screen for 100″; scale linearly (e.g., ~1.65 m for ~150″).
• 🎥 Mounting: Ceiling mount just behind the player; centre the lens and use minimal keystone for maximum sharpness.
• 🖥️ Aspect: Native 16:9. For 4:3 enclosures, use your PC’s scaling/cropping to fill height.

What’s in the Box

• 📦 ViewSonic LS711HD Projector
• 📦 Remote & Batteries
• 📦 Power Cable
• 📦 Documentation

Order Yours Today

🏌️ Want bright, close-range projection without shadows? Choose the ViewSonic LS711HD for laser reliability, short-throw placement and easy alignment in your simulator bay.

FAQ

Q: How close can it sit for a 100″ screen?
A: About 3.6 ft / 1.1 m thanks to the 0.49 throw ratio.

Q: Is it bright enough for rooms with some light?
A: Yes — it’s rated up to 4200 ANSI lumens; controlling stray light will always improve contrast.

Q: Does it support quick alignment?
A: Yes — H/V keystone and 4-corner adjustment are built in; it also supports 360° and portrait install modes.

Q: How long does the laser last?
A: Up to around 30,000 hours depending on mode and usage.
